DOMINO 24 & 48 USER MANUAL
www.adblighting.com
User Manual - page 62
Issue 1.2
18.10.5 PINNED VIDEO
When a submaster or the cue list is “selected’, a video display is automatically pinned. Press;
[select], [f/a] (playback or cue list to pin).
To select a specific position for the pinned display;
HOLD [function], tap [f/a] (video 1 to 4).
(Video 1 is at the top left of the screen and video 4 is at the bottom).
Holding [function] and tapping [f/a] (video 1 to 4) again, turns off (unpins) the display.
Press [select] (de-selects select) to finish.
To remove all pinned displays press;
[select], [remove].
During normal operation, when any of the 3 video pages (below) are displayed they will
cover any displays that you “pin”. Up to 4 pinned displays may be viewed at the same time.
18.11 DIAGNOSTICS
The DOMINO provides diagnostics which allow you to;
• Test the operation of all buttons, LEDS, faders, the EDIT wheel
• Check internal battery voltage and charge condition.
• Check memory capacity and usage.
18.11.1 DIAGNOSTICS MODE
To select diagnostics mode;
HOLD [function] tap [ok], release [function].
Several unlabelled Channel B [f/a] buttons flash to show they are active.
18.11.2 LED AND BUTTON TEST
Enter diagnostics mode (above) then press channel B [f/a] (1).
All LEDs should be lit. If a LED is not lit, then there is a possible problem with the LED.
To test a button, press the button and its LED will go off. This indicates a command from that
button has been received at the processor and it is operating correctly.
To exit;
HOLD [function], tap [ok].
18.11.3 FADER TEST
Enter diagnostics mode (above) then press channel B [f/a] (2).
To test a fader, press the [f/a] button for that fader then move the fader. The display reads
from 0 to 255 as the fader is moved through its range.
To exit;
HOLD [function], tap [ok].
18.11.4 EDIT WHEEL TEST
Enter diagnostics mode (above) then press channel B [f/a] (3)
Rotate the EDIT wheel to test it. The display should smoothly count up or down as the wheel
is rotated.
To exit;
HOLD [function], tap [ok].
18.11.5 BATTERY TEST
Enter diagnostics mode (above) then press channel B [f/a] (5).
