ADCMT 12704A User Manual

3-2
12704A Resistivity Chamber Operation Manual
3.1 Connecting to the Measuring Instruments
3. Measurement Method
3.1 Connecting to the Measuring Instruments
This section describes the procedure of connecting the 12704A to measuring instruments. For
the details of each instrument, refer to its operation manual.
The following table shows connectable instruments and necessary cables and adapter.
Table 3-1 Connectable Measuring Instruments and Necessary Cables/Adapter
Measuring instrument
Cable/adapter
8340A 8240 8252 5450 5451
INPUT
A01009
Input TRIAX-TRIAX cable
0.5, 1, 1.5, 2, 4 m
   
CC010004
Input S. TRIAX-TRIAX cable
0.5, 1, 1.5, 2 m

*1
V SOURCE
A01044
Output safety-safety cable
1 m, red and black one each

CC010005
Output safety-safety cable
1 m, red
  
A08531
Banana adapter
Red and black one each

LID
SIGNAL
A01036
Input BNC-BNC cable
1.5 m
   
*1 A combination of A01009 and CC015003 (S.TRIAXP-high voltage TRIAXJ connector)
is also available.
