Appendix 7 – Cable and connector specications
RS232 serial mouse to PS/2 converter cable
5 1CLK DCD
NC
NC
NC
1 2
DAT RXD
2 5TXD GND
3 4GND
Female
65
43
21
DTR
4 6+5V DSR
6 7-12V RTS
3 TXD (-12V)
8 CTS
9 RI
6pin mini-DIN
female
9pin D-type
female
AdderView CATx to power switch cable
Power switch to power switch daisy chain cable
9pin D-type female
4pin RJ9
4pin RJ9
4pin RJ9
RS232 serial ash upgrade cable
9pin D-type female 9pin D-type male
