ADDER CATx User Manual

 




103
Appendix 9 – Supported video modes
The following video modes are supported and can be automatically congured
by the AdderView CATx units. If a recognised video mode cannot be found, the
AdderView CATx will gradually change some of the key parameters to discover
whether a video lock can be achieved. Support for VESA GTF (Generalized
Timing Formula) is available and can be enabled via the Advanced Unit
Conguration screen.
The half width video modes capture every other pixel. These are not generally
recommended for normal use but may be used for emergency access to high
resolution, high frequency system screens. Half width screens can be expanded
to normal width using the scaling features of the viewer.
vesa 720 x 400 @ 85Hz
vesa 640 x 480 @ 60Hz
vesa 640 x 480 @ 72Hz
vesa 640 x 480 @ 75Hz
vesa 640 x 480 @ 85Hz
vesa 800 x 600 @ 56Hz
vesa 800 x 600 @ 60Hz
vesa 800 x 600 @ 72Hz
vesa 800 x 600 @ 75Hz
vesa 800 x 600 @ 85Hz
vesa 1024 x 768 @ 60Hz
vesa 1024 x 768 @ 70Hz
vesa 1024 x 768 @ 75Hz
vesa 1024 x 768 @ 85Hz
vesa 1152 x 864 @ 75Hz
vesa 1280 x 960 @ 60Hz
vesa 1280 x 1024 @ 60Hz
vesa 1280 x 1024 @ 75Hz
vesa 1600 x 1200 @ 60Hz
vesa 1600 x 1200 @ 65Hz half-width
vesa 1600 x 1200 @ 70Hz half-width
vesa 1600 x 1200 @ 75Hz half-width
vesa 1600 x 1200 @ 85Hz half-width
vesa 720 x 400 @ 70Hz*
sun 1152 x 900 @ 66Hz
sun 1152 x 900 @ 76Hz
sun 1280 x 1024 @ 67Hz
apple 640 x 480 @ 67Hz
apple 832 x 624 @ 75Hz
apple 1152 x 870 @ 75Hz
1900 x 1200 @ 60Hz**
* Not actually a VESA mode but a common DOS/BIOS mode
** May also work on some systems when the operating temperature of the AdderView
CATx is controlled.
