Modem Conguration
This page allows you to congure the
COM1 serial port located at the rear of
the AdderView CATx IP.
Server IP / Client IP
When a user dials into the AdderView
CATx IP via a modem or ISDN adapter,
the AdderView CATx IP sets up a
temporary two-device network using
PPP (Point to Point Protocol). For this
purpose, both devices must have
‘dummy’ IP addresses so that they
can communicate correctly. These
two addresses can be almost anything
expressed in the quad octet format (i.e. 192.168.3.1.). However, it is advisable
not to make them the same as the real IP addresses used by either the remote
system or the AdderView CATx.
Baud Rate
This option congures the speed of the serial connection between the
AdderView CATx IP and a connected modem or ISDN terminal adapter. The
default setting is 115200. The other communication settings are xed as: No
parity, 8 bit word, 1 stop bit.
Init String
The codes entered here are used to prepare the connected modem or ISDN
terminal adapter for use with the AdderView CATx IP. The default code is
a Hayes-compatible string to congure auto answer mode and would be
understood by the vast majority of modem/ISDN devices. The code is sent when
the AdderView CATx IP is rst switched on or whenever the Initialize button is
clicked.
Initialize Port
When selected, this option sends the characters entered in the ‘Init string’ eld
to the connected modem or ISDN terminal adapter.
Restore Defaults
When selected, this option resets the ‘Baud rate’ and ‘Init string’ values to their
original default settings.
Reset Conguration
This option allows you to completely reset the IP portion of the AdderView CATx
IP unit.
WARNING: This process will remove all network and modem/ISDN settings
and return the unit to use its original state. A complete reconguration will be
required before the IP features of the unit can be used.
To reset the AdderView CATx IP conguration
1 With the Reset Conguration option highlighted, press .
2 Access the Congure IP port option to view the initial IP conguration
screens. See Initial IP conguration for details.
