IRIS-4 Technical Reference Manual.docx 12/01/2023 page 37
6.11.2.4 Entry delay
This option lets you set up the entry delay timer. The default is 10 seconds.
6.11.2.5 Set status relay
This option lets you allocate which relay output is to be the set/unset status
indicator and to set the default state to “Normally open” or “Normally closed”.
The default is “Normally open”.
6.11.2.6 Alarm status relay
This option lets you enable relay D as the alarm status indicator. This means that
if any (enabled) pin Inputs are in an alarm state, the relay will change state
according to what the default state is set to (default is normally open).
ENS4-21 Fire
Sets the IRIS-4 4xx to EN54-21 Fire conformances. For further details, see chapter 7 “Installation for EN54-21
conformance”.
VdS 2463 Intruder
Sets the terminal to VdS 2463 Intruder conformances. For further details, see chapter 8 “Installation for VdS
2463 Compliance”.
VdS 2463 Fire
Sets the terminal to VdS 2463 Fire conformances. For further details, see chapter 8 “Installation for VdS 2463
Compliance”.
ILKA mode + PSU
Sets the terminal to customer specific PSU monitoring with predefined threshold and dial port settings.
ILKA mode
Sets the terminal to customer specific PSU monitoring with predefined threshold and dial port settings.
Tamper detection
Enables or disables tamper detection on the terminal, which lets you connect an external tamper switch, for
example, for the cover of the terminal enclosure.
INCERT 2+/3
Enables terminals that support dual path IP communications to support Belgian INCERT T015
The INCERT standard T015 requires Grade 2+ and Grade 3 installations to signal alarms over both paths.
When the alarm format is SIA, the terminal will also insert a SIA Path modifier (pt) on test alarms (event
codes RX and RP) to show the path over which the alarm is sent:
01 = Ethernet
02 = Wi-Fi
03 = Cellular
Note: This function only works over Ethernet and cellular and not PSTN.
