Focus Spot 6Z DMX Modes & Values
ADJ Products, LLC - www.adj.com - Focus Spot 6Z User Manual Page 21
ADJ Focus Spot 6Z - DMX Modes and Values
Supports software version 1.2.2 and up.
Features subject to change without notice.
Channel Mode
Values Traits
Basic Standard Ext
21 25 29
LED Refresh Rate (cont’d from previous page)
062 1420 Hz
063 1430 Hz
064 1440 Hz
065 1450 Hz
066 1460 Hz
067 1470 Hz
068 1480 Hz
069 1490 Hz
070 1500 Hz
071 2500 Hz
072 4000 Hz
073 5000 Hz
074 6000 Hz
075 10,000 Hz
076 15,000 Hz
077 20,000 Hz
078 25,000 Hz
079 Disable LED Refresh Rate
Function
080 - 089 Enable blackout while Pan/Tilt moving
090 - 099 Disable blackout while Pan/Tilt moving
100 - 109 Enable blackout while color changing
110 - 119 Disable blackout while color changing
120 - 129 Enable blackout while gobo changing
130 - 139 Disable blackout while gobo changing
Reset
140 - 149 Reset All
150 - 159 Reset Pan/Tilt
160 - 169 Reset Color and Gobo
170 - 179 Reset Eects and Focus
CONTINUED ON NEXT PAGE
