Focus Spot 6Z DMX Modes & Values
ADJ Focus Spot 6Z - DMX Modes and Values
Supports software version 1.2.2 and up.
Features subject to change without notice.
Channel Mode
Values Traits
Basic Standard Ext
1 1 1 000 - 255 Pan Movement, 8-bit
2 2 000 - 255 Pan Fine Control, 16-bit
2 3 3 000 - 255 Tilt Movement, 8-bit
4 4 000 - 255 Tilt Fine Control, 16-bit
3 5 5
Color Wheel 1
000 - 015 Open / white
016 - 031 Red
032 - 047 Orange
048 - 063 Green
064 - 079 Light Blue
080 - 095 Purple
096 - 111 Magenta
112 - 127 Yellow
128 - 189 Clockwise, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise, slow to fast
4 6 6
Color Wheel 2
000 - 015 Open / white
016 - 031 Orange Red
032 - 047 Yellow Green
048 - 063 Peacock Blue
064 - 079 CTO
080 - 095 CTB
096 - 111 Flourescent Blue
112 - 127 Light Yellow
128 - 189 Clockwise, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise, slow to fast
5 7 7
Gobo 1, Continuous Rotation (see Gobos section for gobo patterns)
000 - 009 Open
010 - 019 Gobo 1
CONTINUED ON NEXT PAGE
