ADJ FOC635 - Page 15

ADJ Products, LLC - www.adj.com - Focus Spot 6Z User Manual Page 15
Focus Spot 6Z DMX Modes & Values
ADJ Focus Spot 6Z - DMX Modes and Values
Supports software version 1.2.2 and up.
Features subject to change without notice.
Channel Mode
Values Traits
Basic Standard Ext
5 7 7
Gobo 1, Continuous Rotation (see Gobos section for gobo patterns) (cont’d
from prev page)
020 - 029 Gobo 2
030 - 039 Gobo 3
040 - 049 Gobo 4
050 - 059 Gobo 5
060 - 069 Gobo 6
070 - 079 Gobo 7
080 - 094 Gobo 1 shake, slow to fast
095 - 109 Gobo 2 shake, slow to fast
110 - 124 Gobo 3 shake, slow to fast
125 - 139 Gobo 4 shake, slow to fast
140 - 154 Gobo 5 shake, slow to fast
155 - 169 Gobo 6 shake, slow to fast
170 - 189 Gobo 7 shake, slow to fast
190 - 221 Clockwise, fast to slow
222 - 223 No rotation
224 - 255 Counter-clockwise, slow to fast
6 8 8
Gobo 1 Rotation
000 - 127 Indexing
128 - 189 Clockwise, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise, slow to fast
7 9 9
Gobo 2, Continuous Rotation (see Gobos section for gobo patterns)
000 - 009 Open
010 - 019 Gobo 1
020 - 029 Gobo 2
030 - 039 Gobo 3
040 - 049 Gobo 4
050 - 059 Gobo 5
060 - 069 Gobo 6
CONTINUED ON NEXT PAGE
