Focus Spot 6Z DMX Modes & Values
ADJ Focus Spot 6Z - DMX Modes and Values
Supports software version 1.2.2 and up.
Features subject to change without notice.
Channel Mode
Values Traits
Basic Standard Ext
7 9 9
Gobo 2, Continuous Rotation (see Gobos section for gobo patterns) (cont’d
from previous page)
070 - 079 Gobo 7
080 - 094 Gobo 1 shake, slow to fast
095 - 109 Gobo 2 shake, slow to fast
110 - 124 Gobo 3 shake, slow to fast
125 - 139 Gobo 4 shake, slow to fast
140 - 154 Gobo 5 shake, slow to fast
155 - 169 Gobo 6 shake, slow to fast
170 - 189 Gobo 7 shake, slow to fast
190 - 221 Clockwise, fast to slow
222 - 223 No rotation
224 - 255 Counter-clockwise, slow to fast
8 10 10
Gobo 2 Rotation
000 - 127 Indexing
128 - 189 Clockwise, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise, slow to fast
9 11 11
Shutter, Strobe
000 - 031 No function (shutter closed)
032 - 063 Shutter open
064 - 095 Strobe, slow to fast
096 - 127 Shutter open
128 - 159 Pulse eect, slow to fast
160 - 191 Shutter open
192 - 223 Random strobe, slow to fast
224 - 255 Shutter open
10 12 12 000 - 255 Dimmer Intensity, 0 to 100%
13 000 - 255 Dimmer Fine Control, 0 to 100%
CONTINUED ON NEXT PAGE
