Focus Spot 6Z DMX Modes & Values
ADJ Focus Spot 6Z - DMX Modes and Values
Supports software version 1.2.2 and up.
Features subject to change without notice.
Channel Mode
Values Traits
Basic Standard Ext
11 13 14
Prism 1
000 - 031 Open
032 - 255 6 facet prism
12 14 15
Prism 1 Indexing and Rotation
000 - 127 Indexing
128 - 189 Clockwise, fast to slow
190 - 193 No rotation
194 - 255 Counter-clockwise, slow to fast
16 000 - 255 Prism 1 ne indexing, 16-bit
13 15 17
Prism 2
000 - 031 Open
032 - 255 5 Linear prism
14 16 18
Prism 2 Indexing and Rotation
000 - 127 Indexing
128 - 189 Clockwise, fast to slow
190- 193 No rotation
194 - 255 Counter-clockwise, slow to fast
19 000 - 255 Prism 2 ne indexing, 16-bit
15 17 20 000 - 255 Focus adjustment, far to near
16 18 21 000 - 255 Zoom, min to max beam angle
22 000 - 255 Zoom ne indexing
17 19 23
Iris
000 - 191 Indexing
192 - 223 Pulse Open, slow to fast
224 - 255 Pulse Close, fast to slow
18 20 24 000 - 255 Frost Filter 1, 0 to 100%
19 21 25 000 - 255 Frost Filter 2, 0 to 100%
22 26
Dim Modes
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
