0 = Constant torque curve
1 = Reduce torque curve F
2.0
2 = Reduce torque curve F
3.0
400(Hz)
Volt
100%
V/F pattern setting
CD18
Setting Range 0 ~ 2
Default Value 0
31
Use 2nd V/F to setCD42(43)=7 and terminal FT1(2) close.
2nd V/F setting is at CD56.
1st Maximum
voltage frequency
CD17
V
Setting Range 25.00 ~ 400.00HZ
60HZ region 60.00HZ
50HZ region 50.00HZ
V
100%
0.5HZ 400HZ
setting range
DC braking time
CD19
DC brake at frequency
under 0.5HZ.
Setting Range 0.0 ~ 25.0Sec
Default Value 1.0Sec
F
Constant power
Constant torque
F
(HZ)
0 25sec
DC
