32
DC braking power
CD20
CD20 setting DC voltage
gain various braking
power.
F
(HZ)
25sec
DC Voltage
DC
250
0
Setting Range 0 ~ 250
Default Value 10
Torque boost
CD21
Torque boosting is used to compensate the torque lost due to stator
resistance. Over boosting will cause over current and high acoustic
noise.
V
100%
0.5(CD17) F(CD17)
25%
0%
Setting Range 0.0 ~ 25.0%
Default Value 0.0%
Second speed
settting
CD22
Setting Range 0.00 ~ 400.00HZ
Default Value 20.00HZ
