with latch function
R and CONTROL POWER not necessary
Remark: STOP command entry from control
terminal FT1 or FT2, and set
CD42(FT1)=5 or CD43(FT2)=5
before operation.
Application circuit
R
COM
FWD STOP
Control power
FWD
STOP
R
R
External over temperature command
(1) FT1=9 (Over temperature switch)
Non-latch trip protect and display “OH“ when switch ON.
FT1
39
3 - WIRE CIRCUIT CONNECTION DIAGRAM
CD42=5
CD12=1
STOP COMMAND
APxG3 OUTPUT
FWD(REV) COMMAND
APxG3 OUTPUT
FWD(REV) COMMAND
(TERMINAL LATCH FUNCTION)
FWD FT1
COM
FWD FT1
COM
To Next Page
