40
FT2 Multi-Function
Terminal 2
CD43
Refer to CD42 description.
Setting Range 0 ~ 15
Default Value 0
Free analog
terminal 1
CD44
Refer to CD45 table.
Setting Range 0 ~ 15
Default Value 0
Free analog
terminal 2
CD45
Setting NO. 11 to use application of example 03.
Setting Range 0 ~ 15
Default Value 0
FA1
FA2
Function
Setting Range
Min-------Max
0 ---------- ----------
1 Acceleration time 1 0 ~ CD02 Content
2 Deceleration time 1 0 ~ CD03 Content
3 Acceleration time 2 0 ~ CD25 Content
4 Deceleration time 2 0 ~ CD26 Content
5 Boost setting 0 ~ 25 %
6 DC Brake time 0 ~ 25 Sec
7 DC Brake Energy 0 ~ 250
8 Speed 2 F-min ~ CD22 Content
9 Speed 3 F-min ~ CD23 Content
10 Speed 4 F-min ~ CD24 Content
11 Fmax F-min ~ CD14 Content
12 Output voltage gain 50% ~ 100%
13 Speed 1 F-min ~ CD14 Content
14 Reserved
15 Reserved
