Version selector
CD52
Select function CD52, then use UP/Down key to select F50.0/F60.0
Version. Press to save it. System will return to the factory
setting and go into waiting mode..
S curve
CD53
Setting S curve non-Linear Accel/Decel Operation from 1 to 10.
Setting 0 is normal operation without S curve.
Setting Range 0 ~ 10
Default Value 0
Setting Range F50.0/F60.0
60HZ region F60.0
50HZ region F50.0
Dynamic braking
energy limit
CD51
The higher the percentage, the more braking energy.
The lower the percentage, the lower braking energy.
Description of regenerative discharge braking active period.
1. 0 ~ 100% Deceleration period
2. 101 ~ 200% Braking active period of
(Decel/accel/constant frequency)
3. 201 ~ 300% Braking active period of
(Decel/accel/constant frequency/stand-by)
Remark : NO.1,2,3 are different working situations, but their braking
energy ranges are 0 ~ 100%.
42
Setting Range 0 ~ 300%
Default Value 100
