(2) Control circuit terminal
MS1-104, MS2-102~137, MS4-337
MS4-307~322
(3) RS485 connector
1 2 3 4 5 6 7 8 9 10 11 12 13 14
MA CF3 MC A/B C VCC FA1 GNDFWDREV FT1 FT2 MT COM
Fault Relay
Contact rating
FM
1A 30VDC
1A 240VAC
11
FA1VCC MAMT MCCF3GND
FT1FWD REV A/BFT2 COM FGC
FT1FWD REV A/BFT2
COM FGC
1-31-1 1-2 1-61-4 1-5 1-7 1-8
GND
2-32-22-1
VCC FA1
2-72-62-4 2-5
MT MA CF3 MC
Fault Relay
Contact rating
1A 30VDC
VR5KB
FM
1A 240VAC
This connector is for both F306 and RS485. Set
CD13 for selection.
※
8765 4321
Symbol Description
VCC Analog source for F306
B Communication signal (S-)
RFA0 Analog input for F306
A Communication signal (S+)
GND Analog common for F306
5V Communication source
EXV Communication common
NO 8 7 6 5 4 3 2 1
Color Black Red Orange Yellow Green Blue Purple Brown
Symbol EXG 5V GND A RFA0 B VCC
Connect to F306 or RS485
