EXAMPLE 03 : Auto multi-speed and time programing
DESCRIPTION :
Speed :CD47=80 (High speed) Speed:CD48=12 (Low speed)
Time:CD59=1.25 Time:CD60=0.18
89
Remark:
1. Setting CD27=16, if noise is much.
2. Setting CD21, if start torque is not enough.
Function setting:
1. CD01=1 8. CD21=8
2. CD58=1 9. CD27=1
3. CD47=80 10. CD59=1.25
4. CD48=12 11. CD60=0.18
5. CD49=0 12. CD61=0
6. CD50=0 13. CD62=0
7. CD00=0 14. CD63=0
5th SPEED (80HZ)
1Hr 25min
6th SPEED (12HZ)
18min
START STOP
Value Description
0 Timer disable
1 Speeds with timer for one cycle then stop
2 Speeds with timer for running continually until receive stop command
3
Speeds with timer for one cycle then stop. There is a stop between each
speed.
4
Speeds with timer for running continually until receive stop command.
There is a stop between each speed.
