Crazy Tower Arcade Manual V7.1
Chapter 08 – Diagrams & Schematics
38 | P a g e
J13
J14
J15
J16
USB To Computer
Coin Door Player-1
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-2
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-3
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
J17
Coin Door Player-4
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
