Version 2 Wiring Colors
J1
J2
J3
J4
No Use
Keypad
1. (Blue) Enter
2. (Green) Down
3. (Red) Select
4. (White) Up
5. (Black) GND
6. No Use
No Use
Player 1 Ticket
1. (Red/White) +12V
2. (White/Black) OUT
3. (Green/White) OPTO1
4. (Black/White) GND
J5
J6
J7
J8
Player 2 Ticket
1. (Red/White) +12V
2. (White/Black) OUT
3. (Green/White) OPTO1
4. (Black/White) GND
Player 3 Ticket
1. (Red/White) +12V
2. (White/Black) OUT
3. (Green/White) OPTO1
4. (Black/White) GND
Player 4 Ticket
1. (Red/White) +12V
2. (White/Black) OUT
3. (Green/White) OPTO1
4. (Black/White) GND
Player 1 Buttons
1. (Red/Black) +12V
2. (Blue/Black) OUT
3. (Black/Red) GND
4. (White/Red) IN1
5. No Use
6. No Use
J9
J10
J11
J12
Player 2 Buttons
1. (Red/Black) +12V
2. (Blue/Black) OUT
3. (Black/Red) GND
4. (White/Red) IN1
5. No Use
6. No Use
Player 3 Buttons
1. (Red/Black) +12V
2. (Blue/Black) OUT
3. (Black/Red) GND
4. (White/Red) IN1
5. No Use
6. No Use
Player 4 Buttons
1. (Red/Black) +12V
2. (Blue/Black) OUT
3. (Black/Red) GND
4. (White/Red) IN1
5. No Use
6. No Use
5V/12V Input DC
J13
J14
J15
J16
USB To Computer
Coin Door Player-1
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Orange/Red) IN2
5. (Blue) GND
6. (Red/Green) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-2
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Orange/Red) IN2
5. (Blue) GND
6. (Red/Green) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-3
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Orange/Red) IN2
5. (Blue) GND
6. (Red/Green) OUT1
7. (Orange) OUT2
8. (Green) +12V
