IRF2000 series - standard Doc v2.7 35
© ads-tec Industrial IT GmbH • Heinrich-Hertz-Str. 1 • 72622 Nürtingen • Germany
7 Putting into operation
7.1 Initial configuration
Recommendation for use:
For the initial configuration, a connection to a PC is required.
Connecting the 24V DC power source
The device can be powered with a 24 VDC power source. The corresponding plug is included in the
scope of delivery of the device (3-pin plug).
Connect the device with the appropriate power source.
Connecting the RJ45 network cable
When placing into operation for the first time, a connection is required between the device and a PC via
an RJ45 network cable.
Connect the device to a PC:
Device LAN connection  PC LAN connection
