IRF2000 series - standard Doc v2.7 39

8 Technical data

IRF2000 series

Operating system Embedded Linux

Configuration protocol http, https

Interfaces IN/OUT (electrically isolated)

WAN RJ45 connections 10/100/1000MBit/s Autocrossover

LAN RJ45 connections 10/100/1000MBit/s Autocrossover

External device dimensions See dimensional drawings in chapter 5.

Weight IRF22xx: approx. 0.7 kg

IRF26xx: approx. 1 kg

Protection class IP20

Pollution degree Pollution degree 2 acc. to IEC 61010-1 and CSA C22.2 No.

142-M1987.

Power supply Voltage: 24 VDC ± 20 %

Requirements for the power supply unit:

• Class PS2 acc. to IEC 62368-1 – or –

Limited Power Source (LPS) acc. to IEC 60950-1

• Short circuit current: < 8 A

• For devices with UL approval: NEC Class 2

Max. current consumption IRF22xx: max. 600 mA @ 24 VDC

IRF26xx: max. 800 mA @ 24 VDC

Ambient temperature in operation -20...+70 °C

for storage -20...+85 °C

Recommendation for use:

Detailed information about the device can be found on our website

http://www.ads-tec.de
