80 OUTPUT DEFINITIONS
Fill in the required data on the worksheet below and follow the programming procedure in the installation manual as you
enter the data during the displays and prompts that appear in sequence.
Notes: 1. For Relays, 4229 and 4204 devices are programmed in *79, *80, and *81 modes.
2. For Powerline Carrier devices (plcd), field
✱
27 must be programmed with a House Code.
3. Tampers of expansion units cannot be used to operate devices.
Activation Type and Detail Event (for zone list/activated by)
Output
Function
Number
(1-48)
Activated by
0=delete
1=zn list
2=zn type
3=zn no.
Zone List
(ZL)
1-8 = list
Zone Type
(ZT)
(see table
below)
Zone No.
(ZN)
00=none
01-64
Partition
Number
(P)
(if using ZT trig)
0 = any
1 = partition 1
2 = partition 2
3 = common
By Zone List
0 = restore
1 = alarm
2 = fault
3 = trouble
By Zone No.
0 = restore
1 = alrm/flt/trbl
Action
0 = off
1 = close 2 secs
2 = stay closed
3 = pulse
4 = toggle
5 = duration 1
††
6 = duration 2
††
Output
Number
1-18= dev
Device
Type
R = relay
T = trigger
X = X10
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
ZONE TYPE/SYSTEM OPERATION – Choices for Zone Types are:
00 = Not Used 05 = Trouble Day/Alarm Night 10 = Interior w/Delay 24 = Silent Burglary
01 = Entry/Exit#1 06 = 24 Hr Silent 12 = Monitor Zone 25 = 24-Hr Non-Alarm
02 = Entry/Exit#2 07 = 24 Hr Audible 14 = Carbon Monoxide§§ 77 = Keyswitch
03 = Perimeter 08 = 24 Hr Aux 16 = Fire w/Verification 81 = AAV Monitor Zone
04 = Interior Follower 09 = Fire 23 = No Alarm Response 90-93 = Configurable
§§ when used with an output function,
the carbon monoxide zone type
activates only upon CO alarms. Does
not activate for trouble conditions.
Choices for System Operation are:
20 = Arming–Stay 38 = Chime 58 = Duress
21 = Arming–Away 39 = Any Fire Alarm 60 = AAV Trigger
22 = Disarming (Code + OFF) 40 = Bypassing 61 = AVS/GSMV session begin §
31 = End of Exit Time 41 = **AC Power Failure 62 = AVS/GSMV session end §
32 = Start of Entry Time 42 = **System Battery Low 66 = Function key†
33 = Any Burglary Alarm 43 = Communication Failure 67 = Bell Failure
36 = **At Bell Timeout***
52 = Kissoff
68 = Telco Line Fault
54 = Fire Zone Reset
78 = Keyswitch red LED†††
79 = Keyswitch green LED†††
Note: In normal operation mode:
Code + # + 7 + NN Key Entry starts Device
Code + # + 8 + NN Key Entry stops Device
** Use 0 (any) for Partition No. (P) entry.
*** Or at Disarming, whichever occurs earlier.
† Use *57 Menu mode to assign the function key.
†† Duration is set in program field *177.
††† Device action not used for these choices.
§ automatically set when appropriate AVS Quick
Command performed.
