– 26 –
Specifications & Accessories
Security Control
Physical: 12-1/2” W x 14-1/2” H x 3” D (318mm x 368mm x 76mm)
Electrical:
VOLTAGE INPUT: 16.5VAC from plug-in 25VA transformer, Ademco No. 1321 (1321CN in Canada)
POWER SHUTDOWN NOTE: System shuts down sensor protection processing if control’s voltage drops below 9.6V.
RECHARGEABLE BACKUP BATTERY: 12VDC, 17AH (sealed lead acid type). Charging Voltage: 13.8VDC.
ALARM SOUNDER: 12V, 2.0 Amp output can drive 12V BELLS or can drive one or two 702 (series
connected) self-contained 20-watt sirens. Do not connect two 702s in parallel.
AUXILIARY POWER OUTPUT: 12VDC, 600mA max.
UL installations: Alarm Sounder plus Auxiliary Power currents should not exceed 600mA total.
FUSE: Battery (3A) No. 90–12 (PC board may have a PTC device instead of a fuse. The PTC serves as an
automatically resetting fuse.)
Communication:
Ademco Contact ID Reporting: 10 characters/sec., DTMF (TouchTone) Data Tones, 1400/2300Hz ACK,
1400Hz KISSOFF.
LINE SEIZE: Double Pole
FCC REGISTRATION No.: 5GBUSA-44003-AL-E
RINGER EQUIVALENCE: 0.1B
Maximum Zone Resistance: Zones 1–8 = 300 ohms excluding EOLR standard zones
Compatible Devices
Touchpads: 6150ADT, 6160ADT, 6160VADT; Touchpad Transceivers: 6150RFADT, 6160RF
6270ADT Touch Screen Touchpad; iCenter Advanced User Interface
RF Receivers: 5881L/5882L: accepts up to 8 transmitters
5881M/5882M: accepts up to 16 transmitters
5881H/5882H: accepts up to system maximum transmitters
5800TM Transmitter Module (used with wireless 2-Way devices)
RF Transceivers: 5883M (accepts up to 16 transmitters); 5883H (accepts up to system max. transmitters)
Zone Expansion: 4219 WIRED EXPANSION MODULE
4229 WIRED EXPANSION/RELAY MODULE
Relay Module: 4204 RELAY MODULE
Phone Modules: 4286 PHONE MODULE
Long Range Radio: 7845GSMADT, 7845i-ent, GSMV-ADT
2-Wire Smoke Detector:
Detector Type
System Sensor Model No.
Photoelectric w/heat sensor 2WT-B
Photoelectric 2W-B
Photoelectric 2151 w/B110LP base
Transformers: 1321: 16.5VAC, 25VA Plug-In Transformer (No. 1321CN in Canada)
1361X10: 16.5VAC, 40VA Powerline Carrier Device Interface AC Transformer
Sounders: AB12M 10” Motorized Bell & Box 749 Speaker/Horn
1011BE12M 10” Motorized Bell & Box 744 Siren Driver
702 Outdoor Siren 745X3 Voice Siren Driver
719 2-Channel Siren 705-820, 5-inch Round Speaker
713 High Power Speaker 713 Speaker
746 Indoor Speaker WAVE Speaker
747 Indoor Siren WAVE2 Two-Tone Siren
747PD Two-Tone Piezo Dynamic Indoor Siren WAVE2PD Two-Tone Piezo Siren
747UL Indoor Siren 5800WAVE Wireless Siren
748 Dual Tone Siren
System Sensor PA400B (beige)/; PA400R (red) Indoor Piezo Sounder
