*57 Function Key Programming Worksheet
Option
Function
A
P1 P2 com
B
P1 P2 com
C
P1 P2 com
D
P1 P2 com
Comments
01 Paging
02 Time Display
03 Arm AWAY
04 Arm STAY
05 Arm NIGHT-STAY
06 Step Arming
07 Device Activation
Device:
08 Comm. Test
09 Macro Key 1
Assign each macro key to only a single partition.
†
10 Macro Key 2
Assign each macro key to only a single partition.
†
11 Macro Key 3
Assign each macro key to only a single partition.
†
12 Macro Key 4
Assign each macro key to only a single partition.
†
00 Emergency Keys:
zone 95 zone 99 zone 96 paging
Personal Emergency
n/a
Silent Alarm
n/a
Audible Alarm
n/a
Fire
n/a
Emergency Keys: A = paired keys [1] / [∗] (zone 95); B = paired keys [∗] / [#] (zone 99); C = paired keys [3] / [#] (zone 96)
† There are only four macros system-wide.
Output Relays/Powerline Carrier Devices (X-10) Worksheet For ∗
∗∗
∗79, ∗
∗∗
∗80 and ∗
∗∗
∗81.
Applicable only if Relays and/or Powerline Carrier Devices are to be used.
∗
∗∗
∗79 RELAY/POWERLINE CARRIER DEVICE (X-10) MAPPING (Must program before using *80)
OUTPUT TYPE
OUTPUT TYPE
Relay X10
Relay X10
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
Output
No.
Module
Addr.
Pos
(1-4)
Unit
No.
Description
01
09
02
10
03
11
04
12
05
13
06
14
07
15
08
16
17
On-Board Trigger 1 norm output =
18
On-Board Trigger 2 norm output =
✱
81 ZONE LISTS FOR OUTPUT DEVICES
Fill in the required data on the worksheet below and follow the procedure in the installation manual as you enter the
data during the displays and prompts that appear in sequence.
Note: Record desired zone numbers below, noting that a list may include any or all of system's zone numbers.
List No. Used For… Contains These Zones…
01
General Purpose (GP)
02
General Purpose
03
Chime-by-Zone or GP
(see field *26 for chime by zone option)
04
Cross Zones or GP
(see field *85 for cross zone timer setting)
05
Night-Stay Zones or GP
06
Dial Delay Disable or GP
(see field *50 for dial delay disable option)
07
Unlimited Reports or GP
(see field *93 for unlimited reports option)
08
General Purpose
09
Zones activating pager 1
10
Zones activating pager 2
11
Zones activating pager 3
12
Zones activating pager 4
To Next Page
