– 8 –
✱
169 PAGER 4 PHONE No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
170 PAGER 4 CHARACTERS
| | | | | | | | | | | | | | |
Enter the optional prefix characters, up to 16 digits. 0–9; #+11 = '
✱
'; #+12 = '#'; #+13 = 2-second pause.
✱
171 PAGER 4 REPORT OPTIONS
[0,0,0]
Part. 1 Part. 2 common
See field ∗162 for reporting options. Select for each
partition (use zone list 12 if using options 12 or 13).
✱
172 PAGER DELAY OPTION FOR ALARMS
[3]
0 = none, 1 = 1 minute, 2 = 2 minutes, 3 = 3 minutes
This delay is for ALL pagers in the system.
MISCELLANEOUS SYSTEM FIELDS ∗
∗∗
∗173-∗
∗∗
∗181
✱
173 RF REPORTING OPTIONS
UL: must be “3” (RF tamper reports and RF
button low battery reports)
[3]
Example: Entering “10” (8 + 2)
enables button-type trans to
send low battery reports and
delay all reports for 28 days.
0 = disable all options
1 = RF Tamper reports during disarm
2 = RF button types send low battery
8 = RF low battery reports delayed (delayed 28 days)
✱
175 UP AND ABOUT TIME
[0]
(hourly increments)
0 = none, 1 = 1 hour, 2 = 2 hours,… 15 = 15 hours
✱
176 LACK OF USAGE OPTION
[0]
1–15 = number of weeks selected (1 week increments)
If panel is not armed within the time period selected, a
report will be sent to the central station.
✱
177 DEVICE DURATION 1, 2
(used in *80 Menu mode-Device Actions 5/6)
[0] [0]
1 2
0 = 15 seconds 6 = 2-1/2 min #+11 = 7 min
1 = 30 seconds 7 = 3 min #+12 = 8 min
2 = 45 seconds 8 = 4 min #+13 = 10 min
3 = 60 seconds 9 = 5 min #+14 = 12 min
4 = 90 seconds #+10 = 6 min #+15 = 15 min
5 = 2 minutes
✱
180 SINGLE ZONE BYPASS
[0]
0 = disable; 1 = enabled
✱
181 50/60 HERTZ AC OPERATION
[0]
0 = 60 Hz; 1 = 50 Hz
CONFIGURABLE ZONE TYPE OPTIONS *183-*181
✱
182 CONFIGURABLE ZONE TYPE 90
IMPORTANT: Be careful when selecting
combinations of options for configurable zone types.
Contradictory options can cause unpredictable
results.
1 2 3 4 5 6 7 8 9 10
Enter the appropriate value for each entry, 1-10, based on the charts provided on the
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
✱
183 ZONE TYPE 90 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique
codes in CID code range 750-789. See
important note in installation instructions.
90 ALARM ID: XXX
TROUBLE ID: XXX
Enter the desired 3-digit Contact ID
®
report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
NOTE: Zone alarm and trouble report codes and
relevant restore codes must be enabled in order for the
configurable zone type codes to be reported.
✱
184 CONFIGURABLE ZONE TYPE 91
UL: Do not configure zones as a fire alarm
or UL burglar alarm zone.
1 2 3 4 5 6 7 8 9 10
Enter the appropriate value for each value, 1-10, based on the charts provided on the
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
✱
185 ZONE TYPE 91 REPORT CODES
See ∗183 for notes.
91 ALARM ID: XXX
TROUBLE ID: XXX
See ∗183 for notes.
