ADTRAN Total Access 600R User Manual

64200600L1#T-31A © 2002, ADTRAN, Inc. Page 25
Total Access 600R User Interface Guide (UIG)
SYSTEM CONFIG>SNMP MENU
SYSTEM CONFIG>SNMP MENU>ACCESS
The Total Access 600R is an SNMP agent. The SNMP Menu parameters set up the manager, communities, and levels.
When set to
O
FF
, SNMP access is denied. When set to
O
N
, the 600R will respond to SNMP managers based on the
configuration. The factory default is
O
N
.
SYSTEM CONFIG>SNMP MENU>COMMUNITIES
SYSTEM CONFIG>SNMP MENU>COMMUNITIES>NAME
This list is used to set up to 60 SNMP communities names that the 600R will allow. This is a text string
for the community name. You can enter up to 31 characters in this field. The factory default is no entry
in the name parameter.
SYSTEM CONFIG>SNMP MENU>COMMUNITIES>PRIVILEGE
The access for this manager can be assigned three levels. The factory default is
N
ONE
.
SYSTEM CONFIG>SNMP MENU>COMMUNITIES>MANAGER IP
This is the IP address of the SNMP manager. If set to 0.0.0.0, any SNMP manager can access the Total
Access 600R for this community. The factory default is
0.0.0.0
.
SYSTEM CONFIG>SNMP MENU>TRAPS
SYSTEM CONFIG>SNMP MENU>TRAPS>MANAGER NAME
The 600R can generate SNMP traps. This list allows up to four managers to be listed to receive traps.
M
ANAGER
N
AME
is the text string describing the name of the entry. It is intended for easy reference and
has no bearing on the SNMP trap function. You can enter up to 31 characters in this field. The factory
default is no entry in the manager name field.
SYSTEM CONFIG>SNMP MENU>TRAPS>MANAGER IP
This is the IP address of the manager that is to receive the traps. The factory default is
0.0.0.0
.
SYSTEM CONFIG>SNMP MENU>FDL
SYSTEM CONFIG>SNMP MENU>FDL>MODE
This enables the FDL (only in ESF mode) to be used for management. Learning mode can also be
enabled so the Total Access 600R can “learn” its IP configuration to be used for its FDL management.
Once it learns this information from, for example a Total Access 4303, the configuration items populate.
The factory default is
O
N
.
SYSTEM CONFIG>SNMP MENU>FDL>LINK IP ADDRESS
This is the local IP address used for the FDL management. The FDL uses a separate IP network for
communication, distinct from the customer data configured under the
R
OUTER
menus. The factory
default is
0.0.0.0
.
N
ONE
No access is allowed for this community or manager.
G
ET
Manager can only read items.
GET/SET
Manager can read and set items.
