Page 64 © 2002, ADTRAN, Inc. 64200600L1#T-31A
Total Access 600R User Interface Guide (UIG)
MODULES>MODULES>STATUS>LCV
Line Code Violations.
MODULES>MODULES>STATUS>SLP
Slip Error Events.
MODULES>MODULES>STATUS>UAS
Unavailable seconds.
MODULES>DS0 MAPS
The
M
ODULES
/DS0 M
APS
menu allows you to map network T1 time slots to the internal router. You can edit one of two
maps stored in nonvolatile memory and make one of the maps the currently active map.
MODULES>DS0 MAPS>ACTIVE MAP
Activates one of the two dedicated maps (M
AP
1 or M
AP
2). Default is M
AP
1.
MODULES>DS0 MAPS>APPLY TEMPLATE TO MAP 1
Choices are C
URRENT
M
AP
1, C
URRENT
M
AP
2, and C
LEAR
M
AP
. Default is C
URRENT
M
AP
1. C
LEAR
M
AP
clears
the entire map.
MODULES>DS0 MAPS>MAP 1
Uses the currently defined map 1. The map 1 allows the user to assign slots and ports to individual DS0s 1-24.
MODULES>DS0 MAPS>MAP 1>DS0
Displays the network T1 time slot to be assigned.
MODULES>DS0 MAPS>MAP 1>SLOT
The first option is
O
PEN
, which unassigns the slot if selected. Use
RCU:TA 600
to map network timeslots to
the router. Pick the appropriate slot and press <Enter>. Default is
O
PEN
.
MODULES>DS0 MAPS>MAP 1>
P
ORT
The selection list shows only the remaining ports available to be assigned. It may be necessary to unassign a
port in order to reassign it elsewhere. For the
RCU:TA 600
, the port choices are
U
NASSIGNED
,
R
OUTER
56K
,
and
R
OUTER
64K
. Default is
N/A
.
MODULES>DS0 MAPS>MAP 1>RBS
Robbed Bit Signaling is
N/A
.
MODULES>DS0 MAPS>APPLY TEMPLATE TO MAP 2
Choices are C
URRENT
M
AP
1, C
URRENT
M
AP
2, and C
LEAR
M
AP
. Default is C
URRENT
M
AP
2. C
LEAR
M
AP
clears
the entire map.
MODULES>DS0 MAPS>MAP 2
Define map 2. The map 2 allows the user to assign slots and ports to individual DS0s 1-24.
