ADTRAN Total Access 600R User Manual

64200600L1#T-31A © 2002, ADTRAN, Inc. Page 63
Total Access 600R User Interface Guide (UIG)
MODULES>MODULES>TEST
These options are used to initiate local and remote loopback tests and display the test status.
MODULES>MODULES>TEST>LOC LB
Loopback of the local unit. Choices are N
ONE
, L
INE
, and P
AYLOAD
. L
INE
L
OOPBACK
loops all of the
received data back toward the network. The transmitted data is the identical line code that was received,
including any bipolar violations. P
AYLOAD
L
OOPBACK
is similar to line loopback except that the framing is
extracted from the received data and then regenerated for the transmitted data. N
ONE
disables the loopback
test. Default is N
ONE
.
MODULES>MODULES>TEST>REM LB
Loopback of remote unit. Choices are N
ONE
, L
INE
, and P
AYLOAD
. L
INE
L
OOPBACK
loops all of the
received data back toward the network. The transmitted data is the identical line code that was received,
including any bipolar violations. P
AYLOAD
L
OOPBACK
is similar to line loopback except that the framing is
extracted from the received data and then regenerated for the transmitted data. N
ONE
disables the loopback
test. Default is N
ONE
.
MODULES>MODULES>TEST>TEST STATUS
Indicates whether a test is in progress.
MODULES>MODULES>STATUS
Displays T1 performance data.
MODULES>MODULES>STATUS>TIME FRAME
Choices are C
URRENT
, 15 M
IN
, and 24 H
R
. Default is C
URRENT
. The performance fields -- either C
UR
-
RENT
, 15 M
IN
, or 24 H
R
. -- provide status on key performance measures as specified in ANSI T1.403 and
AT&T TR 54016 for the T1 port. When C
URRENT
is chosen, the performance data for the current 15 minute
window is shown.
MODULES>MODULES>STATUS>CLEAR
Clears information for the T1 port. Press
Enter
when the cursor is over this field to clear the data.
MODULES>MODULES>STATUS>ES
Errored Seconds. An ES is a second with one or more error events or one or more Out Of Frame events or
one or more Controlled Slips.
MODULES>MODULES>STATUS>SES
Severely Errored Seconds. An SES is a second with 320 or more error events or one or more Out Of Frame
events.
MODULES>MODULES>STATUS>SEF
Severely Errored Frames.
MODULES>MODULES>STATUS>FS
Frame Sync Errors.
