ADTRAN Total Access 600R User Manual

64200600L1#T-31A © 2002, ADTRAN, Inc. Page 37
Total Access 600R User Interface Guide (UIG)
IP F
ILTER
D
EFINES
The IP filter defines apply to any IP packet, whether it is routed or bridged. Up to 32 IP defines can
be specified.
N
AME
Identifies the filter entry. Default is no entry in name field.
S
RC
A
DDR
IP address compared to the source address (dotted decimal
format) Default is
0.0.0.0.
S
RC
M
ASK
Bits which are used in the source comparison. (dotted deci-
mal format) Default is
0.0.0.0.
D
EST
A
DDRESS
IP address compared to the destination address (dotted dec-
imal format). Default is
0.0.0.0.
D
EST
M
ASK
Bits which are used in the destination comparison. (dotted
decimal format) Default is
0.0.0.0.
S
RC PORT
IP source port number used for comparison Range: 0 to
65535. (decimal format) Default is
0.
SRC PORT COMP
Type of comparison that is performed. Default is none.
= means ports equal to
not = means port not equal to
> means port greater than
< means port less than
None - means the source port is not compared
D
EST
P
ORT
IP destination port number used for comparison Range: 0
to 65535. (decimal format) Default is
0.
D
EST
P
ORT
C
OMP
Type of comparison that is performed. Default is none.
= means ports equal to
not = means port not equal to
> means port greater than
< means port less than
None - means the destination port is not compared
P
ROTO
P
ORT
Protocol used for comparison. Range: 0 to 255. (decimal
format) Default is
0.
P
ROTO
P
ORT
C
OMP
Type of comparison that is performed. Default is none.
= means protocols equal to
not = means protocols not equal to
> means protocols greater than
< means protocols less than
None means the protocol is not compared
