Total Access 600R User Interface Guide (UIG)
T
RANSLATION
T
ABLE
This option is only available when
NAT P
ORT
T
RANSLATION
is en-
abled. Add translation entries to “fine tune” special protocols or
specify private addresses.
PUBLIC
A
DDRESS
M
ODE
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled. The public IP address used for this
translation entry can be the NAPT IP address assigned
to the link or can be specified. You specify an address
to direct packets with certain protocols to different
servers. Choices are NAPT A
DDR
and S
PECIFIED
.
Default is NAPT A
DDR
.
P
UBLIC
A
DDRESS
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled and the
P
UBLIC
A
DDRESS
M
ODE
is set to
S
PECIFIED
. Default is 0.0.0.0.
P
ROTOCOL
M
ODE
This option is only available when
NAT PORT TRANSLA-
TION
is enabled. The upper layer protocol that is to be
monitored for translation. For TCP and UDP, a port
number must also be specified. Choices are TCP;
UDP; ICMP; A
NY
(TCP, UDP,
OR
ICMP); A
LL
;
S
PECIFIED
; and N
ONE
. Default is N
ONE
.
PROTOCOL
This option is only available when
NAT PORT TRANSLA-
TION
is enabled and
PROTOCOL MODE
is set to S
PECI
-
FIED
. Default is 0 (decimal).
P
ROTOCOL
T
YPE
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled and
P
ROTOCOL
M
ODE
is set to S
PECI
-
FIED
. Read-only.
P
UBLIC
P
ORT
M
ODE
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled and
P
ROTOCOL
M
ODE
is set to either
TCP or UDP.
The public destination port associated with this entry
can be specified to add more control over certain types
of traffic. Choices are S
PECIFIED
and A
NY
P
ORT
. The
default, A
NY
P
ORT
, covers all port types.
PUBLIC PORT
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled and
P
UBLIC
P
ORT
M
ODE
is set to S
PECI
-
FIED
. However, it will not be available if
P
ROTOCOL
M
ODE
is set to ICMP; A
NY
(TCP, UDP,
OR
ICMP);
A
LL
; S
PECIFIED
; or
N
ONE
. Default is 0 (decimal).
P
UBLIC
P
ORT
T
YPE
This option is only available when
NAT P
ORT
T
RANSLA
-
TION
is enabled and
P
UBLIC
P
ORT
M
ODE
is set to S
PECI
-
FIED
. However, it will not be available if
P
ROTOCOL
M
ODE
is set to ICMP; A
NY
(TCP, UDP,
OR
ICMP);
A
LL
; S
PECIFIED
; or
N
ONE
. Read-only.
