2.5.13.2 FAT / FBF Redundant Connection
Where several FAT terminals need to be connected, or where a redundant connection is required
from several control panels, connect the FAT units via a redundant ring. This requires the installation
of an IFAM ADP-N3E Interface in one panel and (optionally) an IFAM ADP-N3S Interface in a second
panel if required.
See Section 2.4.5.2 for information on mounting options.
Redundant ring adaptors are built into the FAT terminals as standard.
Both power (24V DC)
and data
communications are
distributed around the
ring.
2.5.13.3 FSD Key Deposit Box Connection
The interface is compatible with IFAM SDA-3000 FSD Adaptor Interface.
Key Deposit Box heating power is to be supplied
separately.
Refer to the documentation supplied with the
SDA-3000 for details of the wiring connections
between the interface and the key deposit box
itself.
