Advantage Controls MegatronXS User Manual

37
Pyxis STA Dual Output
Sensors:
- 588 Tagged Polymer & PTSA
- FCLSS Free Chlorine & pH (765)
- CLOSS Chlorine Dioxide & pH (765)
- 772TP Dissolved Oxygen & temp
Wiring for
MegaTron XS
Note: Refer to
full manual for
additional
information
XS Megatron Main, Rev.
VDC Output
Connections
Gnd
Gnd
-12
-12
+12
+12
+5
+5
Aux Flow Inputs
+5
Gnd
Gnd
Input 1
Input 2
Input 3
Input 4
LED
Cable
Comm Card
Slot
Input 1 +
Input 1 -
4-20mA
Slot
Open
System
Slot
+12
-12
+5
+5
WHITE (+4-20)
GRAY (-4-20)
RED (+) 12 VDC
Battery
BROWN ( - ) 12 VDC
Input 2 +
Input 2 -
PINK (+4-20)
Jumper between Input 1 -
and Input 2 -
Wire Color
Red
Brown
White
Pink
Gray*
Blue
Yellow
Green
588
Polymer 4-20mA+
PTSA 4-20mA+
4-20mA -
RS-485 A
RS-485 B
RS-485 C, ground
12 VDC -
12 VDC +
*Internally connected to power ground
** Pyxis 765SS sensor
FCLSS & CLOSS**
Oxidizer 4-20mA+
pH 4-20mA+
4-20mA -
RS-485 A
RS-485 B
ground
12 VDC -
12 VDC +
772TP
DO 4-20mA+
Temp 4-20mA+
4-20mA -
RS-485 A
RS-485 B
ground
12 VDC -
12 VDC +
Controller Wiring
Sensor
588 #1
588 #2
FCLSS #1
FCLSS #2
CLOSS #1
CLOSS #2
772TP #1
772TP #2
Name
FCL2
pH
CLO2
pH
DO
Temp
PTSA
Poly
X.XXX
XX.XX
X.XXX
XX.XX
XX.XX
XXXX.X
XXXX.X
XX.XX
MAX
5.000
14.00
5.000
14.00
20.00
122.0
200.0
20.00
Controller Settings
Units
PPM
PPB
PPM
PPM
PPM
F
#-Units
MIN
00.00
000.0
0.000
00.00
0.000
00.00
00.00
032.0
