Chapter 4 Command Set 4-169
Chapter 4
4080, 4080D
Baud Rate
Code (Hex)
Baud Rate
03 1200 bps
04 2400 bps
05 4800 bps
06 9600 bps
07 19.2 Kbps
08 38.4 Kbps
Table 4-7:
Baudrate Codes
NOTICE: You can change all configuration parameters dynamically
except checksum and baud rate parameters. They can only be altered
when the INIT* terminal is grounded.
%AANNTTCCFF
Response: !AA(cr) if the command is valid.
?AA(cr) if an invalid parameter was entered or if the INIT*
terminal was not grounded when attempting to change baud
rate or checksum setting.
There is no response if the module detects a syntax error or
communication error, or if the specified address does not exist.
! is a delimiter character indicating a valid command was
received.
? is a delimiter character indicating the command was invalid.
AA (range 00-FF) represents the 2-character hexadecimal
address of a counter/frequency module.
(cr) is the terminating character, carriage return (0Dh).
Example command: %0120510600(cr)
response: !20(cr)
The ADAM 4080D module at address 01 is configured to new
address 20, frequency measurement module, baud rate 9600,
frequency gate time 0.1 second and no checksum checking or
generation.
The response indicates that the command was received.
Wait seven seconds to let the new configuration settings take
effect before you issue a new command to the module.
