Utility Software
A-
2 ADAM 4100 Series User’s Manual
ADAM-4100 Utility Software
Together with the ADAM modules, you will find a utility disk
containing utility software with the following capabilities:
- Module configuration
- Module calibration
- Data Input and Output
- Autoscan of connected modules
- Terminal emulation
The following text will give you a brief instruction on how to use the
program.
A.1 Utility overview
Search the installed modules
The main screen consists of a menu bar at the top and a status field
which displays information about the connected modules. When the
modules are well connected, you may start the program and search for
the modules by clicking the search icon as below. Please do check if
the COM port and related settings are correct.
Figure A-1 Search screen
