ADAM-4100 I/O Modbus Mapping Table

B-

ADAM 4100 Series User’s Manual

B.2 ADAM-4118 8-channel Thermocouple Input Module

ADDR 4X Channel Item Attribute Memo

00001 0 Burn-out R

00002 1 Burn-out R

00003 2 Burn-out R

00004 3 Burn-out R

00005 4 Burn-out R

00006 5 Burn-out R

00007 6 Burn-out R

00008 7 Burn-out R

40001 0 Current Value R

40002 1 Current Value R

40003 2 Current Value R

40004 3 Current Value R

40005 4 Current Value R

40006 5 Current Value R

40007 6 Current Value R

40008 7 Current Value R

40201 0 Type Code R/W

40202 1 Type Code R/W

40203 2 Type Code R/W

40204 3 Type Code R/W

40205 4 Type Code R/W

40206 5 Type Code R/W

40207 6 Type Code R/W

40208 7 Type Code R/W

40211

Module Name 1

R 0x41 0x18

40212

Module Name 2

R 0x50 0x00

40213

Version 1 R 0xa2 0x00

40214

Version 2 R 0x00 0x00

40221

Channel Enable

R/W 0x00 0xff
