Appendix B
Appendix B ADAM-4100 I/O Modbus Mapping Table B-
5
B.3 ADAM-4150 Digital Input/Output Module
ADDR 0X Channel Item Attribute Memo
00001 0 DI Signal R
00002 1 DI Signal R
00003 2 DI Signal R
00004 3 DI Signal R
00005 4 DI Signal R
00006 5 DI Signal R
00007 6 DI Signal R
00017 0 DO Signal W
00018 1 DO Signal W
00019 2 DO Signal W
00020 3 DO Signal W
00021 4 DO Signal W
00022 5 DO Signal W
00023 6 DO Signal W
00024 7 DO Signal W
00033
0
Counter Mode:
START(1)/STOP(0)
R/W
00034
0
Counter Mode: Clear
Counter(1)
R/W
00035
0
Counter Mode: Clear
Overflow
R/W
00036
0
Counter Mode: Latch
Status(read)/Clear
Status(Write)
R/W
00037
1
Counter Mode:
START(1)/STOP(0)
R/W
00038
1
Counter Mode: Clear
Counter(1)
R/W
00039
1
Counter Mode: Clear
Overflow
R/W
00040
1
Counter Mode: Latch
Status(read)/Clear
Status(Write)
R/W
00041
2
Counter Mode:
START(1)/STOP(0)
R/W
00042
2
Counter Mode: Clear
Counter(1)
R/W
