ADAM-4100 I/O Modbus Mapping Table
B-
10 ADAM 4100 Series User’s Manual
ADDR 0X Channel Item Attribute Memo
40001~40016 0~7
For Pulse Output L level time
Unit:0.1ms 8 Channel[32Bits]
R/W
0xa2 0x00
40017~40032 0~7
For Pulse Output H level time
Unit:0.1ms 8 Channel[32Bits]
R/W
0xB0
0x01
40033~40048 0~7
Set Absolute pulse(Set to
0=Continue mode) 8
Channel[32Bits]
R/W
Enable:
0x00 0x01
40049~40064 0~7
Set Incremental pulse 8
Channel[32Bits]
R/W
Occur:
0x00 0x01
40065~40072 0~7 DO mode R/W
40073~40088 0~7 DO Low Delay width R/W
40089~40104 0~7 DO High Delay width R/W
40211 Module Name 1 R
40212 Module Name 2 R
40213 Versoin 1 R
40214 Versoin 2 R
40215 Comm Safety Enable R
40216 Comm Safety Flag R
40301 Reserved
40302 Reserved
40303 DO data in word R/W
