Command Set
4-
8 ADAM 4100 Series User’s Manual
Table 4-1 Input Range Codes (Type Code)
ADAM-4117
Input Range Code (Hex) Input Range
07 4~20 mA
08 ± 10 V
09 ± 5 V
0A ± 1 V
0B ± 500 mV
0C ± 150 mV
0D ± 20 mA
15 ± 15 V
48 0 ~ 10 V
49 0 ~ 5 V
4A 0 ~ 1 V
4B 0 ~ 500 mV
4C 0 ~ 150 mV
4D 0 ~ 20 mA
55 0 ~ 15 V
ADAM-4118
Input Range Code (Hex) Input Range
00 ± 15 mV
01 ± 50 mV
02 ± 100 mV
03 ± 500 mV
04 ± 1 V
05 ± 2.5 V
06 ± 20 mA
07 4~20 mA
0E Type J Thermocouple 0
0
to 760
0
C
0F Type K Thermocouple 0
0
to 1370
0
C
10 Type T Thermocouple -100
0
to 400
0
C
11 Type E Thermocouple 0
0
to 1000
0
C
12 Type R Thermocouple 500
0
to 1750
0
C
13 Type S Thermocouple 500
0
to 1750
0
C
14 Type B Thermocouple 500
0
to 1800
0
C
