Advantech ADAM-5510/P31 User Manual

4-8 ADAM-5510/P31
I/O Modules
Application wiring
Figure 4-5: Millivolt and volt input
Figure 4-6: Process current input
Note: To keep measurement accuracy please short the
channels that are not in use.
-
+
V1-
V1+
V0-
V0+
1
0 - 20 mA
0.1%
125
Ω
I
in
1
V0+
V0-
V1+
V1-
V
+
-
mV/V
