3 AIMB-784 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
SATA hard disk drive interface: Six on-board SATA III connectors support
Advanced Host controller interface (AHCI) technology and have data transmis-
sion rates up to 600 MB/s.
System Chipset: Q87
1.3.2 Memory
RAM: Up to 32 GB in four 240-pin DIMM sockets. Supports dual-channel DDR3
1333/1600 SDRAM.
– AIMB-784G2: supports non-ECC unbuffered DIMMs and do not support any
memory configuration that mixes non-ECC with ECC unbuffered DIMMs
1.3.3 Input/Output
PCIe slot: 1 PCIe x16 expansion slot, 1 PCIe x4 expansion slot, and 1 PCIe x1
expansion slots.
PCI Bus: 4 PCI slots, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: Configured to LPT1 or disabled. Standard DB-25
female connector cable is a optional accessory. LPT1 supports EPP/SPP/ECP.
Serial port: Six serial ports, one is RS-232/422/485 with hardware auto-flow
control and three are RS-232. One DB-9 connectors located in rear panel are
RS-232
Keyboard and PS/2 mouse connector: Two 6-pin mini-DIN connectors are
located on the mounting bracket for easy connection to PS/2 keyboard and
mouse.
USB port: Supports up to 13 USB 3.0/2.0 ports for G2 SKU with transmission
rates up to 5 Gb/s.
LPC: One LPC connector to support Advantech LPC modules, such as TPM
module.
GPIO: AIMB-784 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
1.3.4 Graphics
Both dual and quad core processors use integrated Intel HD Graphics.
Display memory: 1 GB maximum shared memory with 2 GB and above system
memory installed
DVI-D: Up to resolution 1920 x 1200 @ 60 Hz refresh rate
VGA: Up to 1920 x 2000 resolution @ 60 Hz refresh rate
1.3.5 Ethernet LAN
Supports single/dual 10/100/1000Base-T Ethernet port (s) via PCIe x1 bus
which provides a 500 MB/s data transmission rate.
Interface: 10/100/1000Base-T
Controller: Intel I217LM(PHY) for LAN1, Intel I211AT for LAN2
Note! A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.
