15 AIMB-784 User Manual
Chapter 2 Connecting Peripherals
2.3 USB Ports (LAN1_USB910, LAN2_USB12, USB3,
USB56, USB78, USB1112 & USB1314)
These ports support Plug & Play and hot swapping for up to 127 external devices.
The USB 1/2/13/14 ports comply up to USB specification rev. 3.0. Transmission rates
of up to 5 Gb/s and fuse protection are supported. The USB interface can be disabled
in the system BIOS setup.
The AIMB-784 is equipped with one or two high-performance 1000 Mbps Ethernet
LANs. They are supported by all major network operating systems. The RJ-45 jacks
on the rear plate provide convenient 1000Base-T operation.
If all USB ports are used, USB power is recommended to switch to +5 V instead of +5
V_DUAL.
