Advantech AIMB-784 - Board Layout: Jumper and Connector Locations

AIMB-784 User Manual 6
1.5 Board Layout: Jumper and Connector
Locations
Figure 1.1 Jumper and Connector Locations
Figure 1.2 I/O connectors
KBMS1
USB 3
PCI4
PCIe x1
PCIe x4
DVI1
DVI2
VGA_COM1
LAN1_USB910
DIM MB2
DIM MB1
DIM MA2
DIM MA1
LPT1
USB1314
COM4
USB56
USB78
USB1112
CPUFAN1
COM2
COM 5
COM6
COM3
LAN2_USB12
Audio
KBMS2
PCIe x16
JFP1+JFP2
JFP3
LPC
EATXPW R1
CPU1
GPIO1
VOLT1
PSON1
LANLED1SPDIF_OUT1
FPAUD1
ATX12V 1
SYSFAN1
SYSFAN2
SPI_CN1
SMBUS1
SPI1
JIR1+
JWDT1+
JOBS1
JCASE1
JCMOS1
JUSB_2
JUSB_1
PCI3
PCI2
PCI1
JPCICLK1
JME1
AIMB-784G2
