AIMB-784 User Manual
Chapter 2
Connecting
Peripherals
2.20
PCIEX1_1
2.21
Auxiliary 4-pin power connector (A
TX12V1)
T
o ensure th
e enough power is supplie
d to
the motherboard, one auxiliary 4-pin
power connector is available on the AIMB-
784. A
TX1 must be used to provide suffi-
cient 12 V power to ensure the st
able operation of the system.
PCIe x1
A
TX12V1
34
36
