TPC-xx51T/H User Manual 4
1.4 Touchscreen Specifications
Touch Type: 5- wire Resistive
Base Glass Construction: Tempered glass
Resolution: 1024 x 1024
Light Transmission: 80% ± 3% (Measured by BYK-Gardner)
Controller: USB Interface
Lifespan: 1 million touches at single point
1.5 Power
Input Voltage: 24V
DC
+/- 20% (the fuse will become an open circuit if the input
level exceeds 32 V
DC
)
Typical: 24 V
DC
@ 1.9Amp for 12", 1.7Amp for 15"
1.6 I/O Ports Arrangement
The arrangement of the I/O ports is shown in in Figure 1.1
Figure 1.1 I/O Port Arrangement
Note! Touchscreen ITO maybe crash duo to heavy usage .
