21 TPC-xx51T/H User Manual
Appendix A Serial Port Settings
A.4.2 SATA Power connector (CN13)
1655000453 WAFER BOX 2.0mm 5P 180D(M) DIP WO/Pb JIH VEI
A.4.3 Mini PCIE slot (MINIPCIE)
1654002538 MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68N7H
Supports PCI1.1, PCI1.2 Power Definition
* +3.3Vaux was suspend Power , power out to device +3.3V/1.1A
* +3.3V was core power
* +1.5V was core power, power out to device +1.5V/0.5A
Pin Signal Description
1 +V3.3SATA SATA power output 3.3V/1A
2 +V5SATA SATA power output 5V/1A
3 +V12SATA SATA power output 12V/0.5A
4GND GND
5GND GND
Pin Signal Description Pin Signal Description
52
+3.3Vaux /
+3.3V
PCI1.1 was +3.3V, PCI1.2 was +3.3Vaux 51 Reserved NC
50 GND 49 Reserved NC
48 +1.5V 47 Reserved NC
46 NC NC 45 Reserved NC
44 NC NC 43
PIN43_MPCIE_
PWRSEL
The pin to select the Pin 2, 52 power
output for +3.3Vaux or +3.3V (PCI1.1
was Reserved and PIC1.2 was GND
42 NC NC 41 +3.3Vaux
40 GND 39 +3.3Vaux
38 USB_D+
USB serial data interface compliant to
the USB 2.0 specification
37 GND
36 USB_D- 35 GND
34 GND 33 PETp0 PCI Express differential transmit pair
32 SMB_DATA
SMBus data signal compliant to the
SMBus 2.0 specification
31 PETn0
30 SMB_CLK 29 GND
28 +1.5V 27 GND
26 GND 25 PERp0 PCI Express differential receive pair
24 +3.3Vaux 23 PERn0
22 PERST# Functional reset to the card 21 GND
20
W_DISABLE
#
Active low signal. This signal is used by
the system to disable radio operation on
add-in cards that implement radio fre-
quency applications. When implemented,
this signal requires a pull-up resistor on
the card.
19 Reserved NC
18 GND 17 Reserved NC
Key Key Key Key
16 NC NC 15 GND
14 NC NC 13 REFCLK+
12 NC NC 11 REFCLK-
10 NC NC 9 GND
8 NC NC 7 CLKREQ# Reference clock request signal
6 1.5V 5 NC NC
4GND 3NC NC
2
+3.3Vaux /
+3.3V
PCI1.1 was +3.3V , PCI1.2 was
+3.3Vaux
1 WAKE#
Open Drain active Low signal. This sig-
nal is used to request that the system
return from a sleep/suspended state to
service a function initiated wake event.
