UNO-2484G User Manual 26

A.1 CN10 Internal GPIO Pin Header

A.2 Board Connectors and Jumpers

The UNO-2484G board features several connectors and jumpers. The following sec-

tions explain how to configure the UNO-2484G hardware settings.

Table A.1: CN10 Internal GPIO Pin Header

Pin Signal

1+5V

2GPIO0

3GPIO1

4GPIO2

5GPIO3

6GPIO4

7GPIO5

8GPIO6

9GPIO7

10 GND
