Advent VISLINK Newswift 90 User Manual

VISLINK
Newswift 90-180 Motorised Antenna 7
X-Band UBR84/CPR112
Ku-Band PBR120
DBS-Band UBR140
Feed 2 port ( 3,4 port optional)
Power (RF) 500w cw
2.2 DRIVE CONTROL UNIT
Antenna Limits
Polarisation ± 92°
(
Ku, feedhorn cartrid
g
e dependent
)
Azimuth ±180°
Elevation 6° to 90°
Display
Resolution 0.1°
Range ±200°
(Elevation, Azimuth Polarisation)
Power
Electronics
Supply
12v, 2A dc.
Motor Supply 36v, 5A dc.
2.3 MECHANICAL
Azimuth adjustment ± 180°
Elevation adjustment +6° to +90°
Pol. adjustment ± 45° fine (motorised) & 90° coarse (WG switch).
± 90° (motorised) Optional
Motorisation Azimuth
Elevation
Polarisation
Speeds (°/s)
Azimuth 4/0.4/0.1
Elevation 2/0.4/0.1
Polarisation 5/0.4/0.1
Dimensions
0.9m 1.2m 1.5m 1.8m
Antenna Assy Fig 18,19, 31 Fig 20, 21, 22,
31
Fig 23, 24, 25,
31
Fig 26,27
Rotary W/G
(option)
Fig 28 Fig 28, 29 Fig 28, 29 Fig 28, 29
Motor drive Included in antenna ass
y
Weight
94 kg 100kg
