Newswift 90-180 Motorised Antenna 42
4.61.4 ANTENNA DATA
Programmed Data Block
Command: MPD
Response: PDXY<Data Field>
X: Antenna Type identifier.
Y: Message coding structure identifier.
Mantis Antennas. X: ‘a’.
Y <Data Field>
‘0’ Null data field. No programmed data.
‘A’ ±rrr (NOT IMPLEMENTED YET)
Newswift Antennas X: ’b’
Y <Data Field>
‘A’ ±aaaaa±bbbbb±ccccc±ddddd±eeeee±fffff±ggggg±hhhh±iiii±jjjj±kkkk±llll±mm
mm±nnn±ooo
‘B’ ±aaaaa±bbbbb±ccccc±ddddd±eeeee±fffff±ggggg±hhhh±iiii±jjjj±kkkk±llll±mm
mm±nnn±ooo±rrr (NOT IMPLEMENTED YET)
FlyDrive Antennas X: ‘c’
Y <Data Field>
‘A’ ±ccccc±ddddd±ggggg±hhhh±iiii±jjjj±kkkk±llll±mmmm±nnn±ooo±ppp±rrrr
Summit Antennas X: ‘d’
Y <Data Field>
‘A’ ±aaaaa±bbbbb±ccccc±ddddd±eeeee±fffff±ggggg±hhhh±iiii±jjjj±kkkk±llll±mm
mm±nnn±ooo±rrr
Coding :
±aaaaa : Azimuth ACW Tab Negative edge. (Units 0.01°)
±bbbbb : Azimuth ACW Tab Positive edge. (Units 0.01°)
±ccccc : Azimuth Stow Tab Negative edge. (Units 0.01°)
±ddddd : Azimuth Stow Tab Positive edge. (Units 0.01°)
±eeeee : Azimuth CW Tab Negative edge. (Units 0.01°)
±fffff : Azimuth CW Tab Positive edge. (Units 0.01°)
±ggggg : Polarisation ACW edge. (Units 0.01°)
±hhhh : Polarisation Stow Park. (Units 0.1°)
±iiii : Position 1. Int El axis. (Units 0.1°)
±jjjj : Position 1. Inclinometer reading. (Units 0.01°)
±kkkk : Position 1. Estimated RF angle. (Units 0.01°)
±llll : Position 2. Int El axis. (Units 0.1°)
±mmmm : Position 2. Inclinometer reading. (Units 0.01°)
±nnn : Inclinometer calibration offset. (Fine trim) (Units 0.01°)
±ooo : Elevation stow depression position (1). (Units 0.1°)
±ppp : Elevation stow depression position 2. (Units 0.1°)
±rrrr : Compass Offset. (Range : ±180.0) (Units 0.1°)
