2. Installation
2.2 Installation
` Tower
Optional Communication Slot
Standard RS232 to PC
AS400
RJ45 protection for
Tel/Fax/Modem/DSL
Remote control
USB
To external battery
cabinet
DB9
Output to the loads
To the wall socket
SNMP/HTTP
` Rack-Mount
To the wall socket Optional Communication Slot
Output to the load
To external battery
cabinet
Standard RS232 to PC
Remote control
RJ45 protection for Tel/Fax/Modem/DSL
Keep the UPS on a flat, stable surface with a
10cm space around it for proper
ventilation.
